Description
CAPACITY
-
Capacity (Cooling, Btu/hr) : 17061 Btu/hr
-
Capacity (Cooling, Min - Max, Btu/hr) : 4095 - 20473 Btu/ hr
-
Capacity (Cooling, kW) : 5.00 kW
-
Capacity (Cooling, Min - Max, kW) : 1.2 - 6 kW
ENERGY EFFICIENCY
-
ISEER (W/W) : 5.15 W/W
-
EER (Cooling, W/W) : 3.88 W/W
-
Energy Star Rating (Cooling) : 5 Star
NOISE LEVEL
-
Noise Level (Indoor, High/Low, dBA) : 45 / 24 dBA
-
Noise Level (Outdoor, High/Low, dBA) : 50 dBA
ELECTRICAL DATA
-
Power Source(?/V/Hz) : 1 / 230~ / 50
-
Power Consumption(Cooling, W) : 1290 W
-
Operating Current(Cooling, A) : 5.8 A
PHYSICAL SPECIFICATION
-
Gross Dimension (Indoor, WxHxD) : 1.11 m x 29.00 cm x 37.50 cm
-
Gross Dimension (Outdoor, WxHxD) : 92.60 cm x 64.00 cm x 41.20 cm
-
Net Dimension (Indoor, WxHxD) : 1.05 m x 29.90 cm x 21.50 cm
-
Net Dimension (Outdoor, WxHxD) : 79.00 cm x 54.80 cm x 28.50 cm
-
Gross Weight (Indoor, kg) : 13.4 kg
-
Gross Weight (Outdoor, kg) : 31.6 kg
-
Net Weight (Indoor, kg) : 11.4 kg
-
Net Weight (Outdoor, kg) : 26.7 kg
TECHNICAL INFORMATION
-
Piping Length (Max, m) : 30 m
-
Piping Height (Max, m) : 15 m
-
SVC Valve (Liquid (ODxL)) : 6.35
-
SVC Valve (Gas (ODxL)) : 12.7
-
Moisture Removal (l/hr) : 1.93 l/hr
-
Air Circulation (Cooling, ?/min) : 17.30 ?/min
-
Refrigerant (Type) : R32
-
Refrigerant (Charging, kg) : 0.70 kg
-
Refrigerant (Charging, tCO2e) : 0.47 tCO2e
-
Low Ambient (Cooling, ?) : 15~52 ?
-
Outdoor Unit (Compressor Type) : BLDC
-
Outdoor Unit (Anti-Corrosion Fin) : Yes
AIR FLOW
-
WindFree Cooling : Yes
-
Air Direction Control (Up/Down) : Auto
-
Air Direction Control (Left/Right) : Auto
-
Air Flow Control Step (Cool/Fan) : 5/4
AIR PURIFICATION
-
PM 1.0 Filter : No
-
Tri Care Filter : No
-
4-in-1 Care Filter : No
-
Copper Anti-bacterial Filter : Yes
-
Auto Clean (Self Cleaning) : Yes
CONVEIENCE
-
SmartThings : Yes
-
AI Auto Cooling : Yes
-
Motion Detect Sensor : No
-
Freeze Wash : Yes
-
Filter Cleaning Indicatior : Yes
-
Indoor Temp. Display : Yes
-
Display On/Off : Yes
-
Beep On/Off : Yes
-
24-Hour Timer : Yes
-
Auto Changeover : No
-
Auto Restart : yes
OPERATING MODE
-
Auto Mode : Yes
-
Fast Cool : Yes
-
Dry Comfort : Yes
-
Good Sleep : Yes
-
Eco Mode : No
-
5 Step Mode : Yes
-
Dehumidification : Yes
-
Fan Mode : Yes
-
Quiet : Yes
SMART
-
Wi-Fi Embedded : Yes
APP CONNECTIVITY
-
SmartThings App Support : Yes
