Technical/Functional Specification
| Series | | FTXF Series |
| Indoor Model No | | FTXF50UV16V |
| Outdoor Model No | | RXF50UV16V |
| Power supply intake | | Outdoor unit |
| Cooling Capacity Rated Full/Half (min~max) | kW | 5.0 / 2.5 (1.5 ~ 5.75) |
| Cooling Capacity Rated Full/Half (min~max) | Btu/h | 17,100 / 8,550 (5,120 ~ 19,619) |
| Heating Capacity Rated Full/Half (min~max) | kW | 5.5 (1.3 ~ 6.6) |
| Heating Capacity Rated Full/Half (min~max) | Btu/h | 18,770 (4,400 ~ 22,520) |
| Power consumption (Cooling) Rated Full/Half (min~max) | W | 1,270 / 431 (310 ~ 1,620) |
| Power consumption (Heating) Rated Full/Half (min~max) | W | 1,300 (260 ~ 1,800) |
| Annual Power Consumption | kWh | 743.95 |
| ISEER / ISEER Rank | | 5.2 / Inverter – 5 Star |
| Voltage Range | V | 130 – 285 |
| Power Supply | Ph, V, Hz | 1 , 230, 50 |
| Operating Current – Cooling | A | 5.63 |
| Operating Current – Heating | (A) | 5.77 |
| Filters | | PM 2.5 Filter |
| Self Diagnosis | | Yes |
| Sleep Mode | | Yes |
| Timer | | Yes |
| Auto Restart | | Yes |
| Other Convenience Features | | Power airflow dual flaps ; 3D Air flow ; Wide-Angle Louvers ; Vertical auto-swing (up & down) ; New Coanda Airflow ; Power Chill Operation ; Econo Mode ; Smell proof operation ; Auto-Restart after Power Failure, Dew Clean |
